Suitable fpr packing various kinds of regular objects like biscuits, pies , chocolates,bread, instant ,noodles, moon-cakes,drugs, daily applications, industrial parts, paper boxes, tray etc.
Min.order:1 set
Warranty:24 month
Package:Wooden box
Shipping: Ocean freight, Land freight, Air freight
Suitable fpr packing various kinds of regular objects like biscuits, pies , chocolates,bread, instant ,noodles, moon-cakes,drugs, daily applications, industrial parts, paper boxes, tray etc.
Features
1、Dual frequency conversion control, bag length can be set and cut in one step, saving time and film.
2、Interface features easy and quick setting and operation.
3、Self failure diagnosis, clear failure display.
4、High sensitivity photoelectric eye color tracing, numerical input of cutting sealing position for extra accuracy.
5、Temperature independent PID control, more suitable for packaging different materials.
6、Positioned stop function, without sticking knife or wasting film.
7、Simple driving system, reliable working, convenient maintenance.
8、All control is realized through software, easy for function adjusting and technical upgraded.
Model |
TY-250X |
TY-350X |
TY-450X |
TY-600X |
TY-700X |
Max. Width of Film |
Max.250mm |
Max.350mm |
Max.450mm |
Max.600mm |
Max.700mm |
Bag length |
65-190 or 120-280mm |
120-450mm |
120-500mm |
120-600mm |
|
Bag width |
30-110mm |
50-160mm |
50-180mm |
100-280mm |
100-330mm |
Product height |
Max.45mm |
Max.65mm |
Max.80mm |
Max.110mm |
|
Film roll diameter |
Max.320mm |
||||
Packaging rate |
40-230bag/min |
40-150bag/min |
20-150bag/min |
20-130bag/min |
|
Power |
220V 50/60Hz 2.4KW |
220V 50/60Hz 2.8KW |
|||
Machine size |
(L)3920x(W)670 x(H)1320mm |
(L)4020x(W)720 x(H)1320mm |
(L)4020x(W)820 x(H)1450mm |
(L)4020x(W)920 x(H)1460mm |
(L)4020x(W)980 x(H)1480mm |
Machine quality |
About 500kg |
About 550kg |
About 650kg |
About 680kg |
About 720kg |
