Suitable for packing soft, sticky or multi pack products such as towel, tissue, noodles, egg rolls, sausages, ice lolly, ice cream bar, soft candy, cutlery, vegetables, etc.
Min.order:1 set
Warranty:24 month
Package:Wooden box
Shipping: Ocean freight, Land freight, Air freight
Suitable for packing soft, sticky or multi pack products such as towel, tissue, noodles, egg rolls, sausages, ice lolly, ice cream bar, soft candy, cutlery, vegetables, etc.
FEATURE
Kindly Reminder:
We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Model |
TY-250X |
TY-350X |
TY-450X |
TY-600X |
TY-700X |
Max. Width of Film |
Max.250mm |
Max.350mm |
Max.450mm |
Max.600mm |
Max.700mm |
Bag length |
65-190 or 120-280mm |
120-450mm |
120-500mm |
120-600mm |
|
Bag width |
30-110mm |
50-160mm |
50-180mm |
100-280mm |
100-330mm |
Product height |
Max.45mm |
Max.65mm |
Max.80mm |
Max.110mm |
|
Film roll diameter |
Max.320mm |
||||
Packaging rate |
40-230bag/min |
40-150bag/min |
20-150bag/min |
20-130bag/min |
|
Power |
220V 50/60Hz 2.4KW |
220V 50/60Hz 2.8KW |
|||
Machine size |
(L)3920x(W)670x (H)1320mm |
(L)4020x(W)720x (H)1320mm |
(L)4020x(W)820x (H)1450mm |
(L)4020x(W)920x (H)1460mm |
(L)4020x(W)980x (H)1480mm |
Machine quality |
About 500kg |
About 550kg |
About 650kg |
About 680kg |
About 720kg |
